Droscape
A MaleCNS-derived steering model connected to a 2004Scape client
No controller response yet.
The model path is target bearing → MaleCNS visual/ascending cells → 3,781 measured synapses with transmitter-informed modeled signs → bilateral DNa01/DNa02 activity → steering. Game-to-neuron transduction, sign interpretation, rate dynamics, adaptation and the final tile/action adapter are modeled—not measurements from a living fly.
Recent Controller Decisions
Each row is emitted by the running gateway controller. Dispatch proves the client received an action; reward comes from subsequent world-state changes.
The character and controller state come from one server process. Visitors observe the same stream; opening or muting the player does not start another run.
Loaded Steering Circuit
The cells, sides, directed edges, synapse counts and transmitter predictions below come from the official Google Research / Janelia MaleCNS release. The extract is reproducible; the diagram geometry is only a layout.
Provenance: official MaleCNS downloads. The extraction recipe pins every body ID and records hashes for the full 151,856,684-edge table, annotations and neurotransmitter predictions.
References
External material used for the dataset, biological interpretation and benchmark framing. Droscape is not affiliated with these projects or their authors.
- MaleCNS project and downloadsNeuron identities, bilateral annotations, directed edges, synapse counts and transmitter predictions.
- DNa01/DNa02 steering studyExperimental basis for treating DNa01 and DNa02 as low- and high-gain steering outputs.
- Google Research: MaleCNS overviewHigh-level context for the complete male fruit-fly connectome release.
- RuneBenchReference for evaluating agents through RuneScape tasks; Droscape uses its own controller and presentation.
What Enters the Network
RS-SDK exposes a target bearing. The bridge turns that bearing into left/right drive on named visual-projection and ascending cells. Activity then crosses measured edges into DNa01 and DNa02, with signs modeled from the transmitter predictions. The DNa left–right difference controls the next turn; bilateral activity controls stride.
Reward changes only the modeled gain at the RuneScape-to-afferent interface. It never rewrites the connectome weights. Chopping, dialog and inventory safety are declared game adapters, not claimed fly behaviors.
observation = {
target: —,
heading: —,
desired_heading: —,
left_drive: —,
right_drive: —
}What Would Count as Learning?
The topology comes from measured wiring, but “a fly learned RuneScape” would still be too strong: the neural dynamics and reward rule are modeled, and one character is not an experiment. A learning claim needs repeated trials and the controls below.
Task Design
Start with woodcutting
The current routine targets the nearest reachable tree. The DNa readout turns and advances the character one or two tiles at a time. Only when the character is adjacent does the bounded adapter issue “chop”; inventory safety and tutorial dialogs stay outside the neural claim.
What is biological
MaleCNS supplies the 16 traced cells, their bilateral identity, 60 directed edges, 3,781 synapses and transmitter predictions. DNa01/DNa02 are experimentally linked to low/high-gain steering. MaleCNS does not supply an executable mind: rate equations, game sensory encoding, reward adaptation and tile mapping remain explicit modeling choices.
What comes next
The client adapter emits observations and accepts bounded actions. The next research step is repeatable trial reset plus the shuffled-graph and matched-RNN controls.
